OKADA OSC MAGNEETTINEN PULVEROIJA SARJA
AVAA KUVAT KLIKKAAMALLA
OSC-1
item32-01
OSC-2
OSC-3
Features
- Rebar scatterd on demolition site can be collected easily and speedy (Work efficiently)
- Short body and light handling.
- Widest jaw opening in its class.
- Speed valve reduces the cycle time.
- Magnet on-off is linked to arm open & close by foot pedal.
| Unit | OSC-135PAV | OSC-200PAV | |
|---|---|---|---|
| Operating weight | kg | 1420 | 2180 |
| Overall length | mm | 1810 | 2055 |
| Overall height | mm | 1395 | 1585 |
| Max. jaw opening | mm | 720 | 860 |
| Cutter blade length | mm | 150 | 150 |
| Crushing force (center) | kN | 600 | 880 |
| Excavator set pressure | MPa | 35 | 35 |
| Valve | Speed | ||
| Suitable carrier range | Ton | 11～16 | 18～30 |
| Magnet size | mm | 590x380 | 660x450 |
http://okada-aiyon.com/oae/wp-content/uploads/2016/02/Product-Line-Up_180627_Final.compressed.pdf
Linkki YouTube:iin: https://youtu.be/SF3aDi35o-8
Nopeat ja täsmälliset varaosatoimitukset Hollanista ja Suomesta
Valtuutettua huoltopisteitä:
| VÖYRI – VAASA
Infraland Oy |
KOKKOLA
Konehuolto Mikael Sabel Oy |
| ETELÄ-SUOMI – JYVÄSKYLÄ
OP Jasto Oy |
OULU
Mekaner Oy |
